Low Headroom Plain Trolley Hoist manual chain hoist

Low Headroom Plain Trolley Hoist features hoist and trolley in an all-in-one unit for low headroom applications.

Send Inquiry

Product Introduction

Additional features and benefits include:

Crowned tread and flanged wheels to minimize rolling friction
Simple, efficient design
Reduced headroom, side clearances and end approach for easy maneuvering of loads in tight places
Plain trolley mounts in capacities from 1/2 to 6 tons
Geared trolley mounts in capacities from 1-1/2 to 6 tons
Standard hand chain drop 2 feet less than lift (example: 8 foot lift hoist has 6 foot hand chain drop)
Chain containers, zinc-plated load and hand chain, aluminum unwelded hand chain, Latchlok hooks, bronze hooks, bullard hooks, larger beam trolleys, trolley guards and units without Load Limiter™ optional, depending on capacity
Standard Load Limiter™/automatic overload protection
Lifetime warranty
Metric rated

Model	Rated Capacity（kg）	Chain Fall No.	Size	Beam Width（mm）	Thickness of Lower Beam Side T (mm)	Mni Radius of Curve(m)	4M Lifting Height N.W.	3M Lifting Height - kg
YLIT 500	500	1	A	50 - 180	19	0.9	20	24
YLIT 500	500	1	B	180 - 300	19	0.9	21	25
YLIT 1000	1000	1	A	50 - 180	19	0.9	27	32
YLIT 1000	1000	1	B	180 - 300	19	0.9	29	33
YLIT 2000	2000	1	A	58 - 180	19	1.15	44	49
YLIT 2000	2000	1	B	180 - 300	19	1.15	46	50
YLIT 3000	3000	1	A	74 - 180	27	1.5	77	82
YLIT 3000	3000	1	B	180 - 300	27	1.4	79	84
YLIT 5000	5000	2	A	98 - 180	27	2	125	130
YLIT 5000	5000	2	B	180 - 300	27	1.8	129	134
YLIT 10000	10000	3	B	125 - 310	40	1,8	–	–
