Turbine Hand Manual Winch
EXW Price:250kg without wire rope $49/pc Mini Order:1pc
For other parameters please contact Us
Shipment: By sea, air, express
Model: VS250
S.W.L(kg): 250
For wire rope(mm): 5
For other parameters please contact Us
Shipment: By sea, air, express
Model: VS250
S.W.L(kg): 250
For wire rope(mm): 5
Send Inquiry
Product Introduction
Product Description

Model | VS250 | VS500 | VS1000 |
S.W.L(kg) | 250 | 500 | 1000 |
For wire rope(mm) | 5 | 6.8 | 9 |
Length(m) | 20 | 25 | 35 |
Number of layers | 4 | 4 | 4 |
N.W.(kg) | 10 | 16 | 40 |
Capacity(kg) | 250 | 500 | 1000 |
A(mm) | 150 | 180 | 300 |
B(mm) | 330 | 360 | 490 |
C(mm) | 150 | 180 | 300 |
D(mm) | 200 | 260 | 300 |
E(mm) | 240 | 240 | 370 |
∅ x(m) | 5*20 | 6.8*25 | 9*35 |
Drive ratio | 15:1 | 21:1 | 26:1 |





Contact Us
