Self Propelled Mast Lift Platform Electric Aerial Person Working Platform
200kg Self-Propelled Electric Mast Lift Platform
This 200kg Self-Propelled Electric Mast Lift Platforms are the industry solution for increasing worksite productivity.
Ideal for maneuvering in tight spaces, they are excellent for indoor usage.
Main specifications
| Model | GT-B1 | GT-B2 |
| Capacity | 200kg | 200kg |
| Working height | 9000mm | 11000mm |
| Platform height | 7000mm | 9000mm |
| Platform size | 1000*700mm | 1000*700mm |
| Power source | DC 24 / 150 V/Ah | DC 24 / 150 V/Ah |
| Lift motor | 2.20Kw | 2.20Kw |
| Traction motor | 0.50Kw | 0.50Kw |
| Travel speed - raised / stowed | 4.0 / 0.6 km/h | 4.0 / 0.6 km/h |
| Lifting / lowering speed | 50 / 66 mm/s | 50 / 66 mm/s |
| Net weight | 1100kg | 1250kg |
Features and Benefits
• User-friendly control
• Compact and low-weight; fits in most passenger elevators
• Can be driven through doorways with operator on board
• Small working envelope for maneuvering around corners
• On-board diagnostics for convenient service
• Dual front wheel drive
• Solid non-marking tires
• Pothole guards included
• Tilt level sensor with audible alarm
• Standard rear access forklift pocket
• Auxiliary platform lowering – enables descent in the event of a power failure
