Moving Cargo Trolley, Heavy Duty Machine Dolly Skate Machinery Roller
Product Description
The moving cargo trolley can be used alone, or can be used together. A single moving cargo trolley can handle equipment from 2 tons to 100 tons, and a combination of multiple moving cargo trolley can handle large equipment weighing 400 tons to 600 tons. Small moving cargo trolley are heavy-weight transporters that can replace the rollarounds used in traditional handling equipment. It easy to use, save time and effort, is an ideal tool for handling heavy equipment. The small moving cargo trolley can also replace the gantry when some equipment is installed in place.
Advantage of Heavy load moving skate:
Those moving cargo trolleys are small in size but heavy in load.
Forged steel plate with strong bearing capacity.
Wheel material: Silicone resin is strong against pressure. It can also protect the ground and prevent oil pollution; the sliding wheel needs no maintenance, and the surface has a rubber layer to protect the materials and increase the friction.
Stability; large load capacity, can be equipped with a joystick, mobile for easy steering.
Easy operation, as long as it is used with the jacking tool, it can greatly save the work cycle. No maintenance is required, the product itself is simple and requires no maintenance. Easy to use
| Model | Maximum load (T) | Normal rated load (T) | Number of rollers (N) | Dimensions(mm) (L * W * H) | Product weight (kg) |
| CRP-3 | 3 | 2 | 3 | 500*480*115 | 22.5 |
| CRP-4 | 4 | 3 | 4 | 580*520*115 | 31 |
| CRP-5 | 5 | 4 | 5 | 630*550*115 | 40 |
| CRP-10 | 10 | 8 | 4 | 650*560*113 | 67 |
| CRP-15 | 15 | 12 | 5 | 720*620*113 | 88 |
Precautions:
If the tonnage is large, at least 4 or more tanks will work together. During the joint operation, it is necessary to coordinate the movement direction of the tanks. Don't hold back.
During joint operation, the movement direction of each tank car can be operated according to the steering conditions of the wheeled car.
Do not overload, slow down, do not work on uneven ground; prevent the tank car from sliding down from heavy objects, do not work on slopes, and do not carry heavy objects with unstable centers of gravity.
